EN 854 2TE Hydraulic Hose - 2 Ply Textile Braid for Higher Pressure & Robust Applications

This hose shall consist of an oil and water resistant synthetic rubber lining,two of suitabletextile yarn and an oil and weather resistant synthetic rubber cover.

Model:
EN 854 2TE

Quantity:
Availability:





Inquire Add to Basket

Description

FAQ

Our EN 854 2TE hydraulic hose is a purpose-built, high-performance fluid conveyance solution engineered for demanding medium-to-high pressure hydraulic systems. Constructed with a premium oil and water-resistant synthetic rubber inner tube, two layers of high-tensile 2 ply textile braid hydraulic hose reinforcement, and a rugged oil, weather, and abrasion-resistant synthetic rubber cover, this hose delivers uncompromising durability and performance across a wide operating range. Compatible with hydraulic fluids conforming to ISO 6743-4 (excluding HRD R, HFD S, and HFDT), it maintains reliable operation in extreme temperatures from -40°C to +100°C. Designed for industrial procurement specialists and commercial equipment manufacturers, this hose strikes an optimal balance between elevated pressure capacity, flexibility, and weight, outperforming single-braid alternatives while remaining more maneuverable than steel wire-reinforced options.

Fiber weaving	Steel wire winding	Wire braiding machine
Friction testing machine	High-speed joint venture	Storehouse

Core Features & Technical Advantages

Dual-Layer Textile Reinforcement for Superior Pressure Resistance

At the core of our high pressure textile reinforced hydraulic hose is a dual-ply high-tensile textile braid reinforcement structure. This design doubles the tensile strength of single-braid counterparts, delivering a maximum working pressure of up to 8 MPa (1160 PSI) for smaller diameters, with a consistent 4:1 safety factor for burst pressure and 2x working pressure for proof testing. This engineering ensures exceptional resistance to pressure spikes, impulse loads, and repeated flexing, eliminating premature failure in high-demand hydraulic circuits.

Premium Material Construction for Extended Service Life

The hose’s inner tube is formulated to resist degradation from petroleum-based hydraulic fluids, water, and common industrial contaminants, while the outer cover provides outstanding protection against oil splashes, UV exposure, weathering, and physical abrasion. This heavy-duty material pairing makes our robust medium pressure hydraulic hose suitable for both indoor industrial environments and outdoor field operations, reducing unplanned downtime and replacement costs over its service life.

Optimized Flexibility & Lightweight Design for Streamlined Installation

Unlike rigid steel wire-reinforced hoses, our EN 854 2TE hydraulic hose maintains exceptional flexibility and a lightweight profile without sacrificing pressure performance. With minimum bend radii starting at 35mm for the smallest diameter and weight as low as 0.12 kg/m, it enables tight routing in compact machinery enclosures and complex hydraulic systems. This design reduces installation labor, simplifies maintenance, and supports seamless integration into space-constrained equipment designs.

Applications & Industry Use Cases

Our 2 ply textile braid hydraulic hose is engineered for a wide range of heavy-duty industrial and mobile applications, including:

Industrial Machinery & Manufacturing Equipment

Ideal for use in injection molding machines, CNC machining centers, hydraulic power units, and automated production lines, where consistent medium-to-high pressure performance and long-term reliability are critical.

Mobile Hydraulic Equipment

Perfect for construction machinery, agricultural equipment, forestry vehicles, and specialty mobile units, where the hose’s flexibility and pressure capacity support dynamic operation in harsh outdoor conditions.

High-Demand Hydraulic Circuits

Suitable for main hydraulic lines, control circuits, and auxiliary systems in equipment where single-braid hoses cannot deliver the required pressure resistance and durability.

Detailed Technical Specifications

size	Standard			I.D		O.D		max W.P		P.P		min B.P		min B.R		min B.R
	Dash	mm	inch	Min	Max	Mpa	Psi	MPa	Psi	MPa	Psi	MPa	Psi	inch	mm	kg/m
0502TE	-3	5	3/16	4.9	5.2	11.3	12.3	8	1160	16	2320	32	4640	1.38	35	0.12
0602TE	-4	6	1/4	6.5	6.9	12.9	13.9	7.5	1088	15	2176	30	4352	1.58	40	0.14
0802TE	-5	8	5/16	8	8.4	14.4	15.4	6.8	986	13.6	1972	27.2	3944	1.97	50	0.16
1002TE	-6	10	3/8	9.5	10	16	17	6.3	914	12.6	1828	25.2	3656	2.36	60	0.18
1302TE	-8	12	1/2	12.5	13	19.2	20.2	5.8	841	11.6	1682	23.2	3364	2.76	70	0.22
1602TE	-10	16	5/8	15.8	16.5	23.3	24.5	5	725	10	1450	20	2900	3.54	90	0.32
1902TE	-12	19	3/4	19	19.7	26.4	27.6	4.5	653	9	1306	18	2612	4.33	110	0.37
2502TE	-16	25	1	25	25.8	33.8	35	4	580	8	1160	16	2320	5.12	130	0.55

FAQ

Q1:How does the two-ply textile braid design support higher pressure compared to single-braid hoses?

A1:

The EN 854 2TE hose uses two layers of high-tensile textile braids for reinforcement, doubling the strength over single-braid designs while remaining lighter and more flexible than steel wire options. This allows higher working pressures (up to 80 bar / 1160 PSI for smaller sizes) suitable for robust medium-pressure hydraulic systems using petroleum-based fluids, making it ideal for industrial machinery or mobile equipment that requires extra pressure capacity without added bulk.

Q2:What pressure performance can I expect from different hose sizes in this EN 854 2TE series?

A2:

Working pressure (WP) decreases with increasing size to balance flow and strength:

Smaller sizes (3/16"–1/2"): 80–40 bar (1160–580 PSI)
Mid to larger sizes (1"–2"): 25–16 bar (362–232 PSI) Burst pressure is consistently 4:1 (e.g., 320 bar burst for 3/16", 64 bar for 2"), and proof pressure is 2× WP. This range supports reliable higher-pressure applications in robust hydraulic circuits while maintaining the hose's flexibility and ease of use.

Q3:Why is this hose considered robust for demanding medium-pressure applications?

A3:

With two textile braids providing enhanced burst and impulse resistance, combined with an oil-resistant synthetic rubber tube and a durable abrasion/weather-resistant cover, the hose excels in robust medium-pressure scenarios. It handles petroleum hydraulic fluids effectively in industrial or mobile equipment where single-braid hoses may fall short, offering improved longevity and reliability under moderate pressure spikes or repeated flexing.

Q4:How does the weight and bend radius make this hose practical for installation in industrial setups?

A4:

The hose remains relatively lightweight despite the double textile reinforcement: 0.18 kg/m for 3/16", 0.35 kg/m for 1/2", up to 2.20 kg/m for 2". Minimum bend radius scales from 50 mm (3/16") to 630 mm (2"), enabling tight routing in smaller sizes for compact machinery while providing ample space for larger diameters. This combination reduces installation effort and supports smooth integration in higher-pressure robust hydraulic systems.
