FAQ
Q1:What features make the SS01 hose ultra-flexible with a small bend radius for dynamic applications?
A1:
This hose uses a single high-tensile steel wire braid reinforcement with an oil-resistant synthetic rubber inner tube and weather-resistant synthetic rubber cover, optimized for high flexibility. The compact design achieves a minimum bend radius of only 50 mm for the 1/4" size, allowing tight routing and frequent flexing in dynamic hydraulic systems like mining machinery, where standard hoses might kink or restrict movement.
Q2:What pressure performance does the SS01 hose deliver for mining hydraulic systems?
A2:
For the 1/4" (6.3 mm ID) size, the hose supports a maximum working pressure (WP) of 22.5 MPa / 3260 PSI, with proof pressure at 45 MPa and minimum burst pressure at 90 MPa / 6525 PSI (4:1 safety ratio). This provides reliable high-pressure performance for conveying petroleum-based hydraulic fluids, water-based fluids, or ethylene glycol solutions in mining equipment, with strong protection against pressure surges.
Q3:How does the SS01 hose's lightweight design benefit installation and use in dynamic environments?
A3:
At just 0.15 kg/m for the 1/4" size, the hose is lightweight and easy to handle, coil, and install in mobile or vibrating mining machinery. The combination of low weight, small 50 mm bend radius, and durable weather-resistant cover reduces operator effort, minimizes fatigue during assembly, and supports smooth operation in applications requiring constant movement or repositioning.
Q4:What customization and support options are available for this flexible hydraulic hose?
A4:
Special specifications can be developed according to customer requirements, including adjustments to sizes, lengths, or other parameters while complying with standards like GB, DIN, RMA, AS, JIS, and SABS. Free samples are provided for testing, making it easy to evaluate the hose's ultra-flexible performance and small bend radius in your specific mining or dynamic hydraulic system before full adoption.
